QIUSUO Ethylene Oxide Gas Detector Ethylene Oxide Detector with Measuring Range 0-100ppm Resolution 1ppm L-Alarm 10ppm H-Alarm 20ppm Wall-mounted Single Input 4-20mA and RS485 for Metallurgical Gas Detection

About this item:

Test gas: Ethylene Oxide gas

Measuring range: 0-100ppm;Resolution: 1ppm;L-alarm:10ppm;H-alarm: 20ppm

Shell Material of Aluminum

Contact output: Free contact output, max power 1kW

advanced catalytic gas sensor or electrochemical sensor

Introduction:

The fixed gas detector adopts advanced catalytic gas sensor or electrochemical sensor, which can translate the gas concentration in the air to the digital signal output. The detector working with gas controller can be used to detect gas in refinery, chemical plant, LPG station, boiler room, painting plant and other places with gas exists.

Features:

Test gas: ethylene oxide C2H4O

Range: 0-100ppm

Resolution: 1ppm

L-alarm: 10ppm

H-alarm: 20ppm

Explosion proof grade: Exd ⅡC T6 Gb

Response time: <30S

Power supply: DC24V±10%

Working temperature: -20℃～55℃

Output current: 4-20mA

Working humidity: 0-95%RH

Contact output: Free contact output, max power 1kW

Single input: 4~20mA and RS485

Installation method: Wall-mounted

Shell material: Aluminum

Dimensions: 190x150x95mm（L×W×H）
